915nm Fiber Coupled Laser SYSTEM
Specifications: | ||
Model | SDL-808-LLD-200WMFL | |
Output Power @ 25 ℃ | >=200W | |
Laser Central wavelength | 808nm @ 20 degC- 25deg C | |
Spectral Width (FWHM) | <=5nm | |
Operation Mode | CW | |
Wavelength Temperature coeff | <=0.3nm/degC | |
Operating Temperature | 20 degC- 30 degC | |
Storage Temperature | 5 deg C- 50 degC | |
Humidity Range | 10%-75% | |
Fiber Core Diameter | 400 um | |
Fiber Numerical Aperture | 0.22 | |
Fiber Length | >=1.5m | |
Fiber Optic Connector | SMA905/LD80 | |
Laser Head | SDL-LH-1000: 238x100x95mm | |
Power Supply | SDL-PS-1500: 400 x 300 x 150mm | |
Power Supply Control | Through PC | |
Protection Filter Wavelength Range | 1050-1100nm | |
Back Reflection Isolation | >=99% or 30 dB | |
Input voltage | AC, 220V, 50Hz single phase | |
Total Weight | <= 30Kg | |
Expect Life Time | >10000 hours | |
Warranty Time | 1 year |
* Other custom-made design is available, please contact us for details.
