DPSS 532nm Low Noise Green Laser
Specifications:
Model
SDL-532-LN-XXXT
Output Power @ 25 ¡æ
2000~3000mW
Wavelength
532nm
Operation Mode
CW, near TEM00
Beam height from base plate (mm)
45mm
Linear Polarization
>100:1
Beam Diameter at the aperture
~3. 0mm
Beam Divergence (1/e2, Full Angle)
<2.0mrad
Power Stability after warm-up
<1%, <3%, <5% (over 2/4/8 hours)
M2 factor
<2.0mm
Warm-up time
<10 minutes
Dimension of laser head
212 x 88 x 74mm
Power Supply
SDL-PS-500
Dimension of Power Supply
238 x 146 x 94mm
Input Voltage
90-264VAC, 50/60Hz
Modulation
TTL Modulation >5KHz or analog Modulation >2KHz
Operating Temperature
10¡æ¡«35¡æ
Expect life time
10000 hours
Noise of amplitude (rms, 1~20MHz)
<1%
Warranty time
1 year
Note:
See the Glossary and Technology for information about the terms used
In the front of the laser, we add an infrared filter. The residual IR part is less than 10-3. Please refer to the technology page for more information about the filter.
Other Sytles and custom designs are available. Contact us to discuss your needs.
